HXY-A8 氣脹救生衣
收藏
適用范圍 適用于船舶 認可標準 1974年《國際海上人命安全公約》及修正案 MSC.48(66)《國際救生設備規則》及修正案 MSC.81(70)《經修正的救生設備試驗建議》 產品技術參數 形式:單氣囊雙氣室 氣室材料: TPU CO2 氣瓶重量:2*60g 充氣時間:≤5S 使用環境溫度: -30℃~+65℃ 浮力:≥275N 浮力損失:≤5% 適合身高:≥155CM 適合體重:≥43KG 配件:口哨、伙伴繩和提拉襻 HXY-A8 Inflatable Lifejacket The Scope Of Application Applied to ships Approval Standard International Convention for the Safety of Life at Sea,1974,as Amended MSC.48(66)International Life-saving Appliance Code,as Amended MSC.81(70)Revised Recommendation on Testing of Life-saving Appliances,as Amended Product Specifications Type:Single airbag and Two compartments Compartment Material:TPU Co2 Cylinder weight:2*60g Inflation time: 5S Usage environment temperature:-30℃~+65℃ Buoyancy:≥275N Buoyancy Loss;≤5% Fit for height:≥155CM Fit for weight:≥43KG Accessories:whistle 、buddy line and lifting becket
1. 確認救生衣的前后,先把救生衣掛單肩上,手臂先穿過一側帶子。 2.然后手臂再穿過另外 一 側。 3. 系好扣帶并調整帶子到合適的寬度。 4. 直接入水:溶解栓遇水自動發生溶解反應,使膨脹裝置動作刺穿氣瓶往氣囊中充入二氧化碳氣體。 充氣入水:右手用力下拉手動拉繩,使膨脹裝置動作刺穿氣瓶往氣囊中充入二氧化碳氣體。 5. 如果浮力不夠的情況下,左手下拉手動繩打開第二個氣囊,或從吹氣管中往氣囊里吹入氣體。 1.Distinguish the obverse and the reverse sides of life jacket.Hang the life jacket in single shoulder,one arm goes through one side of strap. 2.Then pass the other arm through the other strap. 3.Fasten straps and adjust straps to the proper position. 4.Direct use:the disovling plug dissolves automatically when it mets with water,which makes the expansion device actto pierce the gas cylinder andfll the air bag with carbon dioxide.Use after Inflation:pull sharply on the cord with your right handwhich makes the expansion device act to pierce the gas cylinder and fill the air bag with carbon dioxide. 5.In case of insufficient buovancy.Pull on the cord with your left hand to oen the second airbag,or blow air into airbag through air tube |
